Industrial Automation Products

MOOG • RKD2538378

D633-308B
MODEL # R08KO1M0NSM2
SERVO VALVE
D03 SIZE
MAX FLOW = 5.3 GPM
MAX PRESSURE = 5000 PSI
ALL PORTS BLOCKED
COMMAND INPUT = +/- 10VDC
BUNA SEALS

MOOG • RKD2324095

D633-313B
SERVO VALVE
MODEL # R16KO1M0NSM2
D03 SIZE
SOLENOID OPERATED
MAX PRESS = 5000 PSI (350 BAR)
RATED FLOW = 40 LPM (10.6 GPM)
4 WAY
CENTER POSITION
CLOSED Y PORT
BUNA SEALS
VOLTAGE = 24 VDC
SIGNAL = 10 VDC

MOOG • RKD2453470

D633-317B
SERVO PROP VALVE
MODEL # R04KO1M0NSM2
D03 SIZE
DIRECT DRIVE W/ INTEGRATED ELECTRONICS
RATED FLOW = 10 LPM (2.6 GPM)
MAX PRESSURE = 5000 PSI (350 BAR)
4 WAY
CENTER SPOOL POSITION
BUNA SEALS
10 VOLT SIGNAL
24 VDC SUPPLY
PIN C ENABLE

MOOG • RKD2318985

D633-332B
DIRECT DRIVE SERVO VALVE
7PIN
350BAR
10V SIGNAL
24V SUPPLY

MOOG • RKD2560574

D633-345B
DISCONTINUED BY MANUFACTURER
SERVO VALVE
D633 SERIES
MODEL 345
24 VDC
350 BAR
10 MA

MOOG • RKD2379669

D633-502B
DISCONTINUED BY MANUFACTURER
SERVO VALVE
D633 SERIES
24 VDC
350 BAR
5 TO 40 L/MIN FLOW RATE
12 MS RESPONSE TIME
1 STAGE
W/ SPOOL AND BUSHING

MOOG • RKD2449016

D633-7115
DISCONTINUED BY MANUFACTURER
SERVO VALVE
350BAR

MOOG • RKD2379672

D633-7368
DISCONTINUED BY MANUFACTURER
SERVO VALVE
DIRECT DRIVE
SIZE 3

MOOG • RKD2455437

D633-7369
DIRECT DRIVE VALVE
1 STAGE
WITH SPOOL AND BUSHING
SIZE 03
ISO 4401-03-03-0-05 (WITH OR WITHOUT LEAKAGE
OIL CONNECTION Y)
350 BAR (5000 PSI)

MOOG • RKD2453473

D633-7396
DISCONTINUED BY MANUFACTURER
SERVO VALVE
MODULATED (PWM) CURRENT OUTPUT STAGE
24 VDC POWER SUPPLY

MOOG • RKD2560577

D633-7404
PROPORTIONAL VALVE
24V
350 BAR

MOOG • RKD2455440

D633-7405
DISCONTINUED BY MANUFACTURER
SERVO-PROPORTIONAL CONTROL VALVE
SERIES D633
SIZE 3
350 BAR
SIGNAL: 750 MA
(A08KA4F0HXY)

MOOG • RKD2560583

D633-7444
DIRECT DRIVE VALVE
24VDC
NO PILOT SUPPLY
DIRECT SPOOL ACTUATION
SINGLE STAGE
SPOOL IN BUSHING

MOOG • RKD2453476

D633-E713A
DISCONTINUED BY MANUFACTURER
SERVO VALVE
HYDRAULIC
PROPORTIONATE

MOOG • RKD2379675

D633D2502B
SERVO CONTROL VALVE
SERIES D633 SINGLE STAGE
MODEL 250
OPERATING PRESSURE RANGE (PORT P A &
B) UP TO 350 BAR (5000 PSI)
TEMP RANGE AMBIENT -20°
C TO + 60°
C (-4°
F TO + 140°
F)
REQUIRES 24VDC POWER SUPPLY
MAX POWER SUPPLY 32VDC

MOOG • RKD2538384

D633D2504B
SERVO CONTROL VALVE
SERIES D633 SINGLE STAGE
MODEL 250
SUPPLY VOLTAGE 24VDC
OPERATING PRESSURE RANGE (PORT P A &
B) UP TO 350 BAR (5000 PSI)
TEMP RANGE AMBIENT -20C TO + 60C (-4F TO + 140F)

MOOG • RKD2324098

D633E714A
CONTROL VALVE
DIRECT-OPERATED
SERIES D633
SIZE 03
350 BAR MAX OPERATING PRESSURE
4-WAY BUSHING SPOOL TYPE
24VDC
TYPE A08KA4M0VLJ

MOOG • RKD2560586

D633Z570B
DISCONTINUED BY MANUFACTURER
SERVO VALVE
SIZE 03
SPECIAL SPECIFICATION
6 + PE POLE
NBR SEAL
CLOSED WITH PLUG
24 VDC

MOOG • RKD2318990

D634-1001
DISCONTINUED BY MANUFACTURER
SERVO PROPORTIONAL VALVE
SERIES D633
SIZE 05

MOOG • RKD2453479

D634-1003
DISCONTINUED BY MANUFACTURER
HYDRAULIC VALVE
TYPE P40KA6M0VSM2
350 BAR
24 VOLT
+/- 10 VOLT SIGNAL

MOOG • RKD2560589

D634-1019
DISCONTINUED BY MANUFACTURER
HYDRAULIC SERVO VALVE
RATED FLOW: 5 TO 100 L/MIN (1.3 TO 26.3 GPM) @ 35 BAR PER LAND
MAXIMUM FLOW: 180 L/MIN
SIZE: 05
MAXIMUM OPERATING PRESSURE: 350 BAR
MOUNTING PATTERN: ISO 4401 SIZE 03 AND 05

MOOG • RKD2318993

D634-317C
PROPORTIONAL VALVE
MECHANICAL
R24KO2M0NSM2

MOOG • RKD2538387

D634-501A
DISCONTINUED BY MANUFACTURER
SERVO PROPORTIONAL DIRECTIONAL CONTROL VALVE
D05 SIZE
MAX FLOW = 26.4 GPM (100 LPM)
MAX PRESSURE = 5000 PSI (350 BAR)
ALL PORTS BLOCKED
BUNA SEALS
PIN C ENABLE &
MONITOR SIGNAL PIN F TO PIN B
REFERENCE SIGNAL = 10 VOLT

MOOG • RKD2538390

D634Z510
HYDRAULIC VALVE
350 BAR
+/- 10 V SIGNAL
24 VDC SUPPLY
