Industrial Automation Products

ALLEN BRADLEY • RKD3547514

806-DS-2045
DRUM SWITCH
REVERSING

ALLEN BRADLEY • RKD3547494

802T-W1HH
LIMIT SWITCH LEVER
CAST ROLLER LEVER
1.5 IN. LEVER LENGTH
NYLON ROLLER
0.75 IN. ROLLER DIAMETER
1 IN. ROLLER WIDTH

ALLEN BRADLEY • RKD3547498

802T-WS
LIMIT SWITCH
OILTIGHT
TYPE 13
STANDARD LIMIT SWITCH
FULL SW HEAD &
BODY
STANDARD NON-PLUG-IN
2 CIRCUITS
WOBBLE STICK
PUSH ACCUATION
STANDARD MOUNTING
5.34"

NYLON
493

ALLEN BRADLEY • RKD3547511

803-NK37
KIT
CAM FOR ROTATING CAM SWITCH

ALLEN BRADLEY • RKD3547490

802T-NX142
OPERATING LEVER
ROD LEVER
STAINLESS STEEL ROD
12 IN LONG
0.25 IN

ALLEN BRADLEY • RKD3547492

802T-NX159
OPERATING LEVER
STAINLESS STEEL ROD
14 IN LONG
0.13 IN
W/ TENSION SPRING

ALLEN BRADLEY • RKD3547488

802T-NX116
CUSTOM NEMA LIMIT SWITCH
METAL
FULL SWITCH (HEAD AND BODY
PLUG-IN STYLE
ROTARY LEVER ARM
4 CIRCUITS
CONDUIT ENTRY
NOT DIRECT ACTING

ALLEN BRADLEY • RKD3547474

802T-K1TPD
LIMIT SWITCH
NEMA TYPE 4 AND 13 OILTIGHT CONSTRUCTION
PLUG-IN
SAFETY SWITCH
SIDE PUSH ROLLER
HORIZONTAL
4-CIRCUIT
WHOLE SWITCH

ALLEN BRADLEY • RKD3547460

802T-HP1N
LIMIT SWITCH
OILTIGHT
ROTARY LEVER ARM
2P
CO
MOUNTABLE

ALLEN BRADLEY • RKD3547472

802T-HW2
STANDARD LIMIT SWITCH
FULL SWITCH - HEAD &
BODY
STANDARD NON-PLUG-IN
2 CIRCUITS
ROTARY LEVER ARM
CLOCKWISE &
COUNTERCLOCKWISE
0.28"
ROLLER WIDTH
1.9"
TO 3"
ADJUSTABLE LENGTH
ADJ. CAST ROLLER LEVER
NYLON
0.75"
ROLLER DIAMETER
350

ALLEN BRADLEY • RKD3547478

802T-KTP
LIMIT SWITCH
NEMA TYPE 4 AND 13 OILTIGHT CONSTRUCTION
PLUG-IN
SIDE PUSH ROLLER
VERTICAL
4-CIRCUIT
10/60 AMP
120/300 VAC
WHOLE SWITCH

ALLEN BRADLEY • RKD3547486

802T-NPU
OIL TIGHT LIMIT SWITCH
10/60 AMP MAX
600VAC MAX

ALLEN BRADLEY • RKD3547456

802T-DTPDJ1
OILTIGHT LIMIT SWITCH
METAL
10 A STANDARD ENERGY
TOP PUSH ROLLER
4 CIRCUITS
QUICK DISCONNECT CONNECTOR
LOW ENERGY
24V DC @1.1A
2 NO CONTACTS
2 NC CONTACTS
STANDARD LOW TEMPRATURE
SNAP ACTING
PUSH ACCUATION
SPRING RETURN
MINI
9 PINS

ALLEN BRADLEY • RKD3547476

802T-K-COVER
DISCONTINUED BY MANUFACTURER
COVER / DATA PLATE
LIMIT SWITCH
FOR 802T SERIES
MOUNTABLE

ALLEN BRADLEY • RKD3547480

802T-NP-COVER
DISCONTINUED BY MANUFACTURER
LIMIT SWITCH COVER PLATE
802T SERIES
METAL
FOR LIMIT SWITCH

ALLEN BRADLEY • RKD3547482

802T-NPTPV
PLUG-IN OILTIGHT LIMIT SWITCH
10 AMP
ROTARY LEVER ARM
4 CIRCUITS
CONDUIT ENTRY
STANDARD CONTACTS
2 NO / 2 NC
SNAP ACTING
1/2"
NPT THREAD
CLOCKWISE &
COUNTER CLOCKWISE
NEUTRAL POSITION
FULL SWITCH (HEAD &
BODY)
FULL FLOURINATED ELASTOMER

ALLEN BRADLEY • RKD3547468

802T-HUW1
LIMIT SWITCH
LEVER ACTUATED
600VAC
10 AMP
OILTIGHT
STANDARD LIMIT SWITCH
FULL SW HEAD &
BODY
STANDARD NON-PLUG-IN
2 CIRCUITS
ROTARY LEVER ARM
CLOCKWISE &
COUNTERCLOCKWISE
MANIFOLD MOUNTING

ALLEN BRADLEY • RKD3547458

802T-H2TP
LIMIT SWITCH
ROTARY LEVER ARM
4P
CO
NEMA 4
13
6P

ALLEN BRADLEY • RKD3547470

802T-HW1A
LIMIT SWITCH
METAL
PLUG-IN
OILTIGHT
NEMA 4/13
MOUNTABLE

ALLEN BRADLEY • RKD3547466

802T-HU
LIMIT SWITCH
STANDARD
FULL SW HEAD &
BODY
STANDARD NON-PLUG-IN
2 CIRCUITS
ROTARY LEVER ARM
CLOCKWISE &
COUNTERCLOCKWISE
MANIFOLD MOUNTING

ALLEN BRADLEY • RKD3547451

802T-DP1
LIMIT SWITCH
PLUG-IN OILTIGHT
W/O LEVER AND BASE
2 CIRCUITS
TYPE 4/13
TOP PUSH ROLLER
STANDARD CONTACTS
1 NORMALLY OPEN CONTACT
1 NORMALLY CLOSED CONTACT

ALLEN BRADLEY • RKD3547444

802T-CTP1
LIMIT SWITCH
PLUG IN OILTIGHT
METAL
10 AMP STANDARD ENERGY
SIDE PUSH ROD
4 CIRCUITS
STANDARD CONTACTS
2 NO CONTACTS
2 NC CONTACTS
STANDARD LOW TEMPRATURE
18?C
110 ?C HIGH TEMP LIMIT
SNAP ACTING
PUSH ACCUATION
SPRING RETURN
SWITCH BO

ALLEN BRADLEY • RKD3547464

802T-HPE
LIMIT SWITCH
NEMA TYPE 4 AND 13 OILTIGHT CONSTRUCTION
PLUG-IN
LEVER TYPE
SPRING RETURN
HIGH OPERATING TORQUE
2-CIRCUIT
CW AND CCW OPERATION
WH

ALLEN BRADLEY • RKD3547453

802T-DTH
LIMIT SWITCH
NEMA TYPE 4 AND 13
OILTIGHT CONSTRUCTION
NON-PLUG-IN
TOP PUSH ROLLER
4 CIRCUIT
HORIZONTAL
LIMIT 600V AC MAX 10 AMP MAX
